Epoxy Coated Pneumatic Actuator with ISO Pad 5211 and Travel Adjustment ±5º for Ball Valves with Limit Switch Boxes
Datos del producto:
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 |
|---|
|
Información detallada |
|||
| Modelo no.: | VS-052 ~ VS-400 | Fuerza: | Neumático |
|---|---|---|---|
| Dirección de la presión: | cilindro de doble acción | Conduciendo: | Actuador neumático |
| Material del piñón: | Acero de aleación endurecido | Revestimiento del piñón: | Niquelado (más de 15um) |
| Cuerpo del actuador: | Extrusión de aluminio | Revestimiento del cuerpo: | Anodizado duro (más de 30um) |
| Casquillo de extremo: | Aluminio de fundición | Recubrimiento de tapa final: | Recubierto de epoxi (más de 80 um) |
| Material de pistón: | Aluminio de fundición | Revestimiento del pistón: | Anodizado duro (más de 30um) |
| Ajuste de viaje: | ± 5º | Material de los resortes: | Acero de alta resistencia a la tracción |
| Recubrimiento de resortes: | Epóxido cubierto | ||
| Resaltar: | ISO Pad 5211 Pneumatic Actuator,Travel Adjustment ±5º Valve Actuator,Limit Switch Boxes Pneumatic Air Actuator |
||
Descripción de producto
Epoxy Coated Pneumatic Actuator with ISO Pad 5211
Premium Features and Specifications
Position Indicator
- Namur mounting position indicator included on all VESON pneumatic actuators
Precision Pinion
- Hardened alloy steel construction with precision grinding
- Nickel plated (over 15μm) for reduced friction and maximum wear resistance
- Fully compliant with ISO5211 & DIN3337 standards
- Custom dimensions available with stainless steel and aluminum alloy options
Durable Actuator Body
- Hard anodized aluminum extrusion (over 30μm) for wear and corrosion protection
- Minimized piston friction
- Optional Epoxy Coated and PTFE Coated treatments available
Corrosion-Resistant End Caps
- Epoxy coated (over 80μm) die casting aluminum construction
- Maximum resistance against corrosive elements
- Optional PTFE Coated treatment available
Precision Piston System
- Hard anodized (over 30μm) die casting aluminum piston
- Precisely balanced with high-quality guides
- Twin rack and pinion design ensures constant torque output
Adjustable Travel
- Standard adjustment of ±5° in both open and closed positions
- Easy access via external adjustment bolts
High Performance Springs
- High tensile steel construction with epoxy coating for corrosion resistance
- Extended service life
- Pre-loaded design allows for safe and rapid disassembly
Durable Bearings & Guides
- Highly durable compound material construction
- Provides high thrust stability with minimal friction
- Extended operational lifespan
Quiere saber más detalles sobre este producto
